UV Sterilizer For Seawater WL-UVD
For more information, please send an email or call our hotline.
The ozone generator system features an integrated design, making installation and operation straightforward. This series of ozone generators utilizes a connectable DTA non-glass discharge core component, ensuring high ozone output and concentration. The power supply employs proprietary technology, offering a well-matched and highly adaptable system.
This equipment uses a specialized gas source processing technology, which is more reliable than other methods, making it particularly suitable for the unique humid environment of swimming pools. The system boasts high operational stability and a long service life.
Components of the Ozone Generator System
-Ozone Generation Unit: Includes the ozone generation chamber, discharge tube, and high-voltage fuse.
-Power Supply Unit: Contains a high-voltage transformer, DC reactor, input reactor, rectifier inverter, etc.
-Control Unit: Comprises circuit boards, power meters, and ozone output adjustment knobs.
-Gas Source Unit: Includes a high-pressure fan or air compressor, and a specialized adsorption drying device.
-Instrumentation and Piping Unit: Consists of gas flow meters, check valves, and regulating valves.
-PLC Control System: Features automatic control.
Features:
-The external electrode tube is made of 316L stainless steel, and the discharge body uses imported dielectric coating materials.
-Utilizes specialized discharge technology, specifically designed for swimming pools, providing strong targeting and high adaptability.
-Adopts a specialized gas source treatment method, featuring high drying efficiency and superior gas source quality, making it more suitable for the humid and corrosive environment of swimming pools.
-The patented enamel discharge body boasts high intrinsic strength, excellent heat and pressure resistance, and is easy to maintain.
-The ozone output can be smoothly adjusted, offering high concentration and large output. -The equipment performs more stably and has a longer lifespan.
-The equipment features a series of operation monitoring and protection functions, including current, voltage, temperature, flow, gas pressure, and operating status.
-The equipment control is available in both manual and automatic types, allowing selection based on usage requirements.
